Trimmers RS

Range RS

Rear 3-point linkage on inter-row tractor

Configuration :

Large version :

Vine rows planted from 1.8m to 3.3m

Arcure version :

Vine rows planted from 2m to 3.5m

NAOTEC patent

Setting

Numerous hydraulic movements

Technical details :

Vertical cuts :

1.55m to 1.85m, 4 to 5 blades, Ø500

Horizontal cuts :

1.20m, 4 blades, Ø500

Hydraulic requirements :

28L/min

Standard equipment :

• Powder-coated twin-beam frame with hydraulic lift
• Hydraulic movements R/L :
– Spacing, horizontal cut
• Manual angle adjustment for vertical cuts
• Row thickness adjustment
• Spring safety device all cuts (vertical and horizontal)
• Pivoting hitch on lifting arm category 2 (1 or 3 possible)
• Hydraulic adjustable variable track
• Hydraulic variable-length drawbar (900mm)
• Electro-hydraulic joystick control 12DE
• All independent and/or synchronized settings
• Dual-pump hydraulic unit with air cooler
• Road signs and lighting
• Road transport width inferior to 2.50m

Optional equipment :

• Hydraulic cutting knives angle
• Cabin-mounted electric tensioners
• Automatic control: joystick control + color screen + sensors : It allows automatic machine adjustment by memorizing row widths and thicknesses, setting road/work/turnover positions
Download the technical sheet
